3800 g General Purpose Linear Imager
From the global leader in imaging technology comes the 3800 g - the newest member of the legendary 3800 family of liner imagers.
The first in a new class of 3800 linear imagers, the g was built to deliver world - class performance for a broad range of market applications .
Featuring an ideal balance of performance , durability , ergonomics , and connectivity solutions , the 3800g delivers years of hassle - free scanning for applications in retail , warehouse , manufacturing , distribution - and all points in - between .
The first linear imager to earn the Adaptus imaging technology brand , the new 3800g is powered by Adaptus 5.0 , delivering breakthrough liner imaging performance and versatility . Fast , intuitive bar code reading across a range of high and low density codes , the 3800 g quickly reads even damaged and poorly printed bar odes - all in a single device .
3800 g Specifications
Performance :
> Iiiumination - 630 NM Visible Red LED
> Receiving Device - 3648 element liner imager
> Reading Distance - From 5 in (1.3 cm) to 18 in (46 cm) on medium density bar codes
> Resolution - 3 mil at 4 in (10 cm) distance
> Horizontal Velocity - 20in (51 cm) per second
> Minimum Symbol Contrast - 20%
> Scan Rate - up to 270 scans per Second
> Decode Rate : 270 decodes per secound
Mechanical / Electrical :
> Length - 4.4 in (11.2 cm)
> Height - 5.9 in (15.0 cm)
> Width - 3.1 in (7.9 cm)
> Weight - 5.6 oz (158.8 g)
> Housing - UL 94V0 grade
Power Supply :
Noise Rejection - Maximum 100mV peak to peak , 10 to 100 KHz
